Recirculating Chillers – 480W to 1000W

Name: Recirculating Chillers - 480W to 1000W
SKU: 38911
Availability: InStock

Cool Support

Cool Savings

Cool Solutions

State-of-the-art Dual-display microprocessor PID controller (set-point + actual) +/-0.1°C
Ultra-low vibration series (OEMs only)
Whisper-Quiet series
Widest choice of options
Build to ISO 9002 CE Standards
US versions UL approved

KT1 Specifications

Dimensions L x W x H	370 x 450 x 540 mm
Cooling capacity (fluid @ 20°C)	1000 watts
Digital temperature display	Dual readoutas standard (set point and indicated temperature)
Temperature adjustable	1°C increments
Temperature stability	+/- 0.1°C
Temperature range	+4° to +35°C
Microprocessor 3 term PID temperature controller.	Easy front panel programming, with auto tune, fuzzy logic, for state-of-the art control accuracy.
Temperature alarm – Standard off-set +/- 10°C	Adjustable High / Low
Low fluid level Alarm	Visual
Low Fluid Flow Alarm	Visual
Auto diagnostic functions	Controller and sensor
System volume	2.0 litres
Pressure control system	Standard fitment internal – user adjustable
Compatible fluids	Hexid fluids / water / propylene glycol
Fluid connections	BSP threaded Male 3⁄4”, Female 1⁄2”. 3⁄8” and 1⁄2” barbs also supplied
Compressor over – load protection	Standard
Noise Level	58dB(A) @ 1 metre
Weight	55kg
Lockable Castors for mobility	Standard, 2 locking
Warranty	2 years parts, one year labour. Optional 3 year comprehensive

Dimensions L x W x H	330 x 315 x 515 mm
Cooling capacity (water @ 17°C)	480 watts
Digital temperature display	Dual readoutas standard (set point and indicated temperature)
Temperature adjustable	1°C increments
Temperature stability	+/- 0.1°C
Temperature range	+4° to +35°C
Extended temperature range – Optional	-15°C
Microprocessor 3 term PID temperature controller.	Easy front panel programming, with auto tune, fuzzy logic, for state-of-the art control accuracy.
Temperature alarm – Standard off-set +/- 10°C	Adjustable High / Low
Low fluid level alarm	Audio/Visual
Auto diagnostic functions	Controller and sensor
System volume	1.5 litres
Pressure control system	Standard fitment internal – user adjustable
Compatible fluids	Hexid fluids / water / propylene glycol
Fluid connections	10mm i.d. hose tails & 1⁄4” BSP female
Compressor over – load protection	Standard
Emergency Off (EMO)	Via main circuit breaker (MCB)
Tool-less access	No user serviceable parts
Noise level	55 dB(A) @ 1 metre
Weight	30kg
Power requirements	2.5 Amps 1ph 208 V 60Hz, 230V 50Hz and 220V 60Hz 4.5 Amps 110v 60Hz also available
Warranty	2 years parts, one year labour. Optional 3 year comprehensive

Dimensions L x W x H	330 x 315 x 515 mm
Cooling capacity (water @ 17°C)	480 watts
Temperature	Fixed temperature operation, factory set at 10°C (20°C ambient)
Temperature stability	+/- 0.2°C (with a stable load)
System volume	1.5 litres
Compatible fluids	Hexid fluids / water / propylene glycol
Fluid connections	10mm i.d. hose tails & 1⁄4” BSP female
Compressor over – load protection	Standard
Emergency Off (EMO)	Via main circuit breaker (MCB)
Tool-less access	No user serviceable parts
Noise level	55 dB(A) @ 1 metre
Weight	30kg
Power requirements	2.5 Amps 1ph, 208 V 60Hz, 230V 50Hz and 220V 60Hz 4.5 Amps 110v 60Hz also available
Warranty	2 years parts, one year labour. Optional 3 year comprehensive
